No Space for Compromises: Bartels Micro Pump mp6

Micropumps transporting the tiniest amounts of gases or liquids can be considered the heart of microfluidics. In many sectors they have become indispensable.

The small power pack mp6 exhibits a flow performance of 6 ml/minute and can deal with a back pressure of 550 mbar, offering universal capabilities for liquids and gases. The pump is ingeniously simple and its advantages are next to the small size and low weight its robustness, long lifetime and high reliability. The pump is driven via frequency and amplitude allowing flexible adjustment in accordance to the system requirements at low energy consumption. Different control units are offered, also battery powered versions for use in portable devices.

Build from plastics, with only one material (PPSU) in contact with the pump medium, the automated serial production offers unbeatable cost effectiveness and may well be used as disposables.

Important advantages for all users result from the radically simple pump design: Injection molded parts for housing and pump chamber, piezo actuators and passive valves constitute the key components. Thus any adaptation to specific requirements concerning flow rate or back pressure is easy to realize. This customization of micropumps and the correspondent electronic controllers is part of the services offered by Bartels microComponents. If requested, the pumps can be fully integrated into complex system designs as well.

Key Features mp6 !

• Piezo membrane pump
• Mass produced micro pump

• Broad performance spectrum

• Low cost, for consumable applications

• Robust for long life permanent installations

• Compact (postage stamp) size

• Only one material in fluid contact

• Unbeatable cost effectiveness

• Low energy consumption

• Intrinsic regulation of flow rate possible
